Huawei S1700 Series - Radius; RADIUS Global Settings

S1700 Managed Series Ethernet Switches
Web User Manual
9 Security
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
168
Item
Description
Start-stop Group
RADIUS
Enable / Disable AAA Network Accounting.
Method 1
Accounting options are as follow:
none: not necessary to account the data accessed by users.
RADIUS: the switch will send accounting message to RADIUS
server which is used to account the data accessed by users.
AAA Accounting Exec
Name
Enter the method list name for AAA switch access accounting.
Method 1 / Method 2
You can choose a variety of authentication methods, but only
method 1 (not method 2) can match the None accounting method.
In practice, the accounting order is from method 1 to method 2. It
will go to the next accounting method only when the present
accounting invalids. The accounting options are as follow:
none: not necessary to account the data accessed by users.
group: the switch will send accounting message to RADIUS server
which is used to account the data accessed by users.
RADIUS: the switch will send accounting packets to the RADIUS
server which is used to account the data accessed by users.
Active / Inactive
Select a method list entry in switch access accounting list, and then
click this button to activate / inactivate the accounting.
Configure
Select a method list entry in switch access accounting list, and then
click this button to configure this accounting method.
Add the Accounting Exec
Step 1 Click Security > AAA.
Step 2 Click Accounting Settings in Tab.
Step 3 Set the parameters in AAA Accounting Exec section.
Step 4 Click Apply button to apply all the changes made.
Step 5 Click the check box of AAA Accounting Exec list on left side, and then click Active button.
----End
9.14 RADIUS
9.14.1 RADIUS Global Settings
Click Security > RADIUS > RADIUS Global Settings, the configuration page is displayed as
follows.
