Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 1-1 Logon Dialog Box
Step 3 Enter Username, Password and Identifying Code into Logon Dialog Box, then click Logon
button.
S1700 factory default username is admin and password is Admin@123.User can modify the
password. Please refer to the description in Security> User Management
Step 4 After successful logon of Web network management system, home page of system appears.
Please refer to Figure 1-2 for introduction of home page.
----End
1.2 Know About Client Interface
Knowing about the client interface is helpful to quickly find operator site, thus improve
operating efficiency.
1.2.1 Client Interface Components
Layout of typical operating interface of Web network management client is described.
The typical operating interface of Web network management is as shown in Fig.1-2
