Huawei S1700 Series - Authorized Status

S1700 Managed Series Ethernet Switches
Web User Manual
9 Security
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
128
Figure 9-9 Interface Settings
Step 4 Modify authentication setting for interface as needed.
Step 5 Click Apply button to apply all the changes made.
----End
CAUTION
1, 802.1X Authentication can not be enabled on the port with MAC authentication enabled.
2, 802.1X Authentication can not be enabled on port with port security enabled.
3, 802.1X Authentication can not be enabled on link aggregation port.
9.2.4 Authorized Status
Click Security>802.1X> Authorized Status to display 802.1X Authorized Status of interface
on switch.
Figure 9-10 Authorized Status
