Huawei S1700 Series Web User Manual

S1700 Managed Series Ethernet Switches
Web User Manual
9 Security
Issue 05 (2012-10-25)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
171
9.14.3 RADIUS Group Server Settings
Click Security > RADIUS > RADIUS Group Server Settings to check the RADIUS group
server on switch, the configuration page is displayed as follows.
Figure 9-60 RADIUS Group Server Settings
Table 9-41 Parameters of RADIUS Group Server Settings
Item
Description
Group Server Name
The RADIUS server group name.
IP Address
RADIUS server IP address on server groups.
CAUTION
All the RADIUS servers are default as "RADIUS" group; the order of the server group is
based on the creating time.
Add the RADIUS Group Server
Step 1 Click Security > RADIUS.
Step 2 Click RADIUS Group Server Settings in Tab.
Step 3 Enter the name to be added in Group Server Name field, and then click Add button to add the
group sever.
Step 4 Click the check box of group sever list on left side, and then click Configure button.
Step 5 Select the RADIUS group sever IP address to be added in drop-down menu.
