Step 3 Configure the needed parameter.
Step 4 Click Apply button to apply all the changes made.
----End
8.2 IPv6 Route
8.2.1 IPv6 Route Table
Click IP Routing>IPv6 Route >IPv6 Route Table; the configuration page is shown as the
figure below.
Figure 8-4 IPv6 Route Table
Table 8-3 Parameters of IPv6 Route Table
Item
Description
Query
Search IPv6 Route Table according to IPv6 address/prefix length.
IPv6 Prefix
Prefix of destination IPv6.
Protocol Type
Routing type.
Next Hop
IPv6 address of the next hop gateway
Interface Name
VLAN number of static routing entry
8.2.2 IPv6 Static/Default Route Configure
Click IP Routing>IPv6 Route >IPv6 Static/Default Route Configure; the configuration is
shown as the figure below.
Figure 8-5 IPv6 Routing
