Preparing the FCU for transport

Close the USB socket with the

corresponding cover.

First undo the end of the high-

pressure INLET hose that is at the

measurement point of the hydraulic

system.

Remove the hose by turning

counterclockwise from the INLET

connection of the FCU.

FCU1310

en(us)

Page 84 / 124

BeWa FCU1310 V300 3371346f en-us 2017-01-27.docx 2017-01-27
