Preparing the FCU for transport
Undo the quick-action coupling of
the return hose by lifting the outer
ring.
Empty the hose into an
unpressurized container.
To let air into the hose, open it by
using a thin object to press in the
check valve on the quick-action
coupling. This means that the fluid
can then quickly drain out of the
hose.
After emptying it, join the two ends
of the hose together. In this way you
can ensure that no more fluid will
leak from the hose during transport.
FCU1310
en(us)
Page 85 / 124
BeWa FCU1310 V300 3371346f en-us 2017-01-27.docx 2017-01-27
