Preparing the FCU for transport
7.
Release the catch (1) and then pull
the socket out of the connector (2).
8.
Close the FCU using both clips.
Make sure that these audibly snap
into place.
9.
Stow the hose and the power supply
in the bag.
10.
The FCU is ready for transport.
