Performing maintenance

Attach the suction hose onto the

INLET connection of the FCU.

Put the free end of the suction

hose into the container with the

filtered oil.

Use the switch on the FCU to

turn its pump on.

FCU1310

en(us)

Page 90 / 124

BeWa FCU1310 V300 3371346f en-us 2017-01-27.docx 2017-01-27
