Clean the suction screen by
blowing it out with compressed air.
Before reassembly, check that the
sealing ring for the connector is
undamaged.
Replace it if necessary.
Before screwing it in place, wet the
sealing ring (C) with some
hydraulic fluid.
Put the suction screen back into
the opening.
FCU1310
en(us)
Page 94 / 124
BeWa FCU1310 V300 3371346f en-us 2017-01-27.docx 2017-01-27
