Performing maintenance

Manually screw the INLET

connector in clockwise.

Using a INLET 19 mm wrench,

tighten the connector,

turning it clockwise.

Note the maximum torque of

25 Nm.

10.

Replacing/cleaning the suction

screen is complete.
