Hydro Mobile F200 - Cantilever Reinforcement Cable Retainer Installations Single Unit Installation

106
1050 lb
476 kg
1050 lb
476 kg
1050 lb
476 kg
1050 lb
476 kg
1050 lb
476 kg
1050 lb
476 kg
1050 lb
476 kg
1050 lb
476 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
775 lb
352 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
550 lb
249 kg
70' (21,3 m)
30' (9,1 m) 30' (9,1 m)
25' (7,6 m) 25' (7,6 m)
20' (6,1 m) 20' (6,1 m)
fi g. 6.22
70' 6" (21,5 m) 60’ 6” (18,4 m) 50’ 6” (15,4 m)
Total 3300 lb
1497 kg
Total 3300 lb
1497 kg
Total 3875 lb
1758 kg
Total 3875 lb
1758 kg
Total 4200 lb
1905 kg
Total 4200 lb
1905 kg
7 - L C
Load Capacities
Cantilever reinforcement cable retainer installation – Single unit linked setup
Cantilever reinforcement cable retainer installation – Single unit linked setup
OVERALL LENGTH OF CONFIGURATION
To ensure safety at all times, refer to load calculation guidelines and warnings on p. 94.
LEGEND
5' (1,5 m) bridge assembly Length of bridge setup
The confi gurations illustrated in fi g. 6.22 (above) require the use of an optional cantilever reinforcement
cable retainer kit.
WARNING
The use of weather protection is
NOT ALLOWED for
installations equipped with cantilever reinforcement
cable retainers. A platform equipped with cantilever
reinforcement cable retainer(s) must be brought back
down to base level when not in use.
WARNING
On an installation using a cantilever reinforcement cable
retainer, the maximum number of workers allowed
on the whole length of the bridge supported by the
cables is
two.
