Hydro Mobile F200 - Motorized Unit Specifi Cations; Fi G. 1.10

12
fi g. 1.9
fi g. 1.10
fi g. 1.11
1 - M U
Motorized Unit Specifi cations
g
Specifi c Features
Specifi c Features
F200 F300
Platform weight
(as shipped)
Gas-powered motorized
unit
On base
6700 lb (3030 kg)
On base
8400 lb (3810 kg)
Electrical motorized unit
On base
7200 lb (3266 kg)
On base
9400 lb (4264 kg)
Maximum load
capacity
Single unit installation
9000 lb at 50'
(4082 kg at 15,2 m)
Multiple units installation
15,500 lb at 115'
(7031 kg at 35 m)
Vertical travel speed Up to 19' (5,8 m) per minute Up to 38' (11,6 m) per minute
Mast section
2 racks
32" x 32" x 60"
(81,3 cm x 81,3 cm x 152,4 cm)
365 lb (166 kg) per section
Bridges
30" (76 cm)
(guardrail included)
31" x 62" x 36" (W x L x H)
(0,8 m x 1,6 m x 0,9 m)
5' (1,5 m)
(guardrail included)
61" x 62" x 36" (W x L x H)
(1,5 m x 1,6 m x 0,9 m)
10' (3 m)
(guardrail included)
120" x 62" x 36" (W x L x H)
(3 m x 1,6 m x 0,9 m)
Twin mast adapter
(guardrail sold separately)
32" x 62" x 36" (W x L x H)
(0,8 m x 1,6 m x 0,9 m)
General Specifi cations
General Specifi cations
Dimensions of the motorized
unit
(as shipped)
On base, with extensions and
with link bridges installed
99 1/2" x 147 1/4" x 102" (W x L x H)
(253 cm x 374 cm x 259 cm)
On base, with extensions and
with link bridges removed
75 1/2" x 147 1/4" x 102" (W x L x H)
(192 cm x 374 cm x 259 cm)
Drive system Rack and pinion drive
Maximum height Up to 500' (152 m) of mast
Distance between tie levels Up to a maximum of 45' (13,7 m)
Freestanding height
Up to 48' (15 m) of mast
using an optional adapter base for freestanding installation (when allowed)
Safety devices
Emergency descent Gravity-activated manual descent system
Overspeed safety device Independent mechanical device
Inclinometer (included with
twin mast adapter)
Analog electronic angle device
Hydraulic Specifi cations
Hydraulic Specifi cations
Component Specifi cations
Double gear pump 2 x 7.25 US GPM (27,44 l/min)
Planetary reducer gear oil
Sunoco Challenge GBO 220 (product # 6048-020)
Warning: do not use in planetary reducer brake
Planetary reducer brake oil
Total Dynatrans MP-AS (product # 406435)
Warning: do not use in planetary reducer gear box
Hydraulic tank capacity 18 US gal (68,2 l) model F200; 36 US gal (136,2 l) model F300
Hydraulic oil Shell Naturelle HF-M biodegradable product code 407-214
Oil fi lter (return) Mfr. model no. Ikron CSG-100-P10-A)
Oil fi lter (pressure) Mfr. model no. Ikron HEK85 20.8-AS-FG101-LC-V
