1 - M U
Engine Specifi cations (gas-powered motorized unit)
Engine Specifi cations (gas-powered motorized unit)
Model Honda GX630
Rated power 20.8 HP @ 3500 rpm
Fuel consumption 1.56 G/hr (6 l/hr)
Spark plug ZFR5F (NGK)
Oil type SAE 10W-30
Gasoline tank capacity 10 US gal (38 l)
Oil capacity 1,8 US qt (1,70 l)
Charging system 12 VDC - 17 ampere-hour
Battery 12 VDC
For any other information regarding the use and the maintenance of Honda engines,
refer to the Honda user’s manual
Motorized Unit Specifi cations
Operation Specifi cations
Wind exposure
Maximum wind speed allowed
During operation 35 mph (56 km/h)
During erecting and dismantling, when using
weather protection and in freestanding
confi guration using an optional adapter base for
freestanding installation (when allowed)
28 mph (45 km/h)
When unit is out of service
102 mph (164 km/h) *
*
The platform must only be used on a mast whose height does not exceed 500’ (152 m)
.
Motor Specifi cations (electrical motorized unit)
Motor Specifi cations (electrical motorized unit)
480 V unit 600 V unit
Brand Toshiba Toshiba
Model 0252SDSR42BP 0252SDSC42BP
Rated power 25 HP (18,5 KW) 25 HP (18,5 KW)
Service factor at full load 1,1 1,1
Rated amperage (nominal) 29A 23A
Power supply – voltage, phase and frequency 480 VAC / 3/60 600 VAC / 3/60
Rotation speed 3600 rpm 3600 rpm
Electrical Specifi cations
Electrical Specifi cations
Requirements for complete F200 unit model and for each side of an F300 unit model
Requirements for complete F200 unit model and for each side of an F300 unit model
480 V unit 600 V unit
Lifting power
F200 model
25 HP 25 HP
Each side of F300 model
Power consumption
(maximum load)
F200 model
1 x 32A 1 x 25A
Each side of F300 model
Starting current
(per single
unit) (peak)
F200 model
Up to 181A Up to 144A
Each side of F300 model
Input power
480 VAC / 3 ph / 60 Hz
(± 5%)
600 VAC / 3 ph / 60 Hz
(± 5%)
Control voltage 12 VDC 12 VDC
Power outlet for hand tool 1 x 120VAC/20A/60 Hz 1 x 120VAC/20A/60 Hz
Cable up to 500' (152 m)
F200 model
1 x 6/4 1 x 8/4
Each side of F300 model
