Hydro Mobile F200 - Non Standard Planking Confi Guration #2; Non Standard Planking Confi Guration #3

114
120
120
120
120
120
63
63
63
63
fi g. 8.28
fi g. 8.29
fi g. 8.30
fi g. 8.31
fi g. 8.32
fi g. 8.33
72
84
63
8 - A
Outriggers
Non Standard Planking Confi gurations
Non Standard Planking Confi guration #2
Outriggers Required for Non Standard planking Confi guration #2
Outriggers Required for Non Standard planking Confi guration #2
Ref Quantity Outrigger
3
2 1/2" x 1 1/2" x 1/8" x 63"
(6,4 cm x 3,8 cm x 0,3 cm x 160 cm)
1
2 1/2” x 1 1/2” x 3/16” x 72”
(6,4 cm x 3,8 cm x 0,5 cm x 183 cm)
1
2 1/2" x 1 1/2" x 1/4" x 84"
(6,4 cm x 3,8 cm x 0,6 cm x 213 cm)
3
2 1/2" x 1 1/2" x 1/4" x 120"
(6,4 cm x 3,8 cm x 0,6 cm x 305 cm)
Outriggers Required for Non Standard planking Confi guration #3
Outriggers Required for Non Standard planking Confi guration #3
Ref Quantity Outrigger
2
2 1/2" x 1 1/2" x 1/8" x 63"
(6,4 cm x 3,8 cm x 0,3 cm x 160 cm)
2
2 1/2" x 1 1/2" x 1/4" x 120"
(6,4 cm x 3,8 cm x 0,6 cm x 305 cm)
Maximum 5 planks
120
120
63
72
84
Any outrigger
according to
requirements
Wall
Bridge
Planking
This planking confi guration can be
used for planking recessed areas
63
Outriggers
Wall
Wall
Planking Bridge
Outriggers
Maximum 8 planks
Non Standard Planking Confi guration #3
