78
fi g. 5.10
5 - C P
F2 – Alerts – gas-powered and electrical units
Control Panel
Screen alerts and instructions
MINOR ALERTS
Alert Event Action UP travel
DOWN
travel
10 FOOT STOP
3 SEC STOP TO VERIF ALL
CLEAR UNDER PLATFORM
Going DOWN, unit stops for 3 seconds
Make sure there are no interferences under the platform
Used in transport platform confi gurations
ALLOWED
NOT
ALLOWED
BOTTOM LIMIT
UPWARD TRAVEL ONLY
Going DOWN, unit stops Bottom limit reached; only upward travel allowed ALLOWED
NOT
ALLOWED
DOOR STATUS
CLOSE THE DOOR FOR OPERATION
Unit stops
Check all doors on the installation and make sure they are
closed properly
NOT
ALLOWED
NOT
ALLOWED
LINK DOOR
CLOSE THE DOOR FOR OPERATION
Unit stops
Check link bridge doors and make sure they are closed
properly
NOT
ALLOWED
NOT
ALLOWED
INCL 1 > 2DEG POS
GO UP OR DOWN TO LEVEL
Going UP, unit keeps moving
Going DOWN see
No action required; motion of unit is adjusted automatically ALLOWED
ALLOWED
(F300 restricted
to 1st speed)
INCL 1 > 2DEG NEG
GO UP OR DOWN TO LEVEL
Going UP, see
Going DOWN, unit keeps moving
No action required; motion of unit is adjusted automatically
ALLOWED
(F300 restricted
to 1st speed)
ALLOWED
INCL 2 > 2DEG POS
GO UP OR DOWN TO LEVEL
Going UP, unit keeps moving
Going DOWN, see
No action required; motion of unit is adjusted automatically ALLOWED
ALLOWED
(F300 restricted
to 1st speed)
INCL 2 > 2DEG NEG
GO UP OR DOWN TO LEVEL
Going UP, see
Going DOWN, unit keeps moving
No action required; motion of unit is adjusted automatically
ALLOWED
(F300 restricted
to 1st speed)
ALLOWED
F200 unit model: unit keeps going
DOWN
F300 unit model: unit keeps going DOWN at 1st speed
F200 unit model: unit keeps going
UP
F300 unit model: unit keeps going UP at 1st speed
1
2
1
2
1
2
