Hypertherm HyPerformance Plasma HPR400 User Manual

Wiring Diagrams
7-2 HPR400XD Auto Gas – 806160
Battery Cap, polarized Cap, non-polarized Cap, feed-thru Circuit breaker Coax shield Current Sensor Current sensor Diode Door interlock Fan Feedthru LC Filter, AC DC supply
Fuse Ground Clamp Ground, Chassis Ground, Earth IGBT Inductor LED Lamp Pin Socket Plug PNP Transistor Potentiometer
Push Button, Normally Closed
MOV
Push Button, Normally Open Receptacle Relay, Coil Relay, Normally Closed Relay, Normally Open Relay, Solid State, AC Relay, Solid State, DC Relay, Solid State, Dry SCR Shield Shunt Spark Gap Resistor

Hypertherm HyPerformance Plasma HPR400 Specifications

General

Duty Cycle	100% at 400 A
Cutting Capacity	up to 50 mm (2 in)
Output Current	30-400 A
Input Voltage	200 – 480 V, 3-PH, 50/60 Hz
Gas Supply	Oxygen, Air, Nitrogen
