Hypertherm XPR170 Replacement Part Procedures

Parts List
5
136 810410 Field Service Bulletin XPR170
Other adapters not shown
Part number Description Location Quantity
015669
Male adapter: 3/8 inch NPT X 1/2 inch
tube
in coolant solenoid valve 1
006099
Coolant drain valve: 1/4 inch NPT X
3/8 inch tube
in the bottom of the coolant
reservoir
1
015073 Adapter: 1/4 inch NPT X 1/4 FPT
in the bottom of the coolant
reservoir
1
015738
Elbow adapter: 1/4 inch NPT X
1/2 inch tube, 45° swivel
in the top of the coolant
reservoir
1
015510 Adapter: 1/4 inch X hexagonal collar
between the flow meter and
coolant reservoir
1
015663 Adapter: 1/4 inch NPT X 1/2 inch tube
in the flow meter and coolant
bypass check valve
2
015668
Elbow adapter: 1/2 inch NPT X
1/2 inch tube, 90°
in the coolant filter (fine)
assembly
2
1048 07 Nut for chopper fitting on the back of chopper 2
015815
Elbow fitting: 1/2 inch tube X 1/2 inch
tube, 90°
on the back of the chopper (2)
and the heat-exchanger inlet (1)
3
015820 Fitting: 1/2 inch tube X 1/2 inch tube heat-exchanger outlet 1
