Hypertherm XPR170 Replacement Part Procedures

Parts List
5
XPR170 Field Service Bulletin 810410 161
Stainless steel and aluminum consumable starter kit with torch (428841)
Part number Description Quantity
420221 Quick-disconnect torch head 1
420288 Nozzle: 40 A 3
420291 Shield: 40 A 2
420297 Nozzle: 60 A 2
420296 Nozzle: 60 A H
2
O1
420306 Nozzle: 80 A 2
420290 Nozzle: 80 A H
2
O2
420469 Shield: 130 A H
2
O 2
420356 Electrode: 130 A – 300 A 3
420315 Nozzle: 130 A 3
420318 Shield: 130 A 2
420472 Shield: 170 A H
2
O 1
420324 Nozzle: 170 A 3
420327 Shield: 170 A 1
420303 Electrode: 40 A – 80 A 3
420309 Shield: 60 A – 80 A 2
420294 Electrode: 40 A – 80 A aluminum air/air 2
420300 Shield: 60 A – 80 A H
2
O 2
420314 Swirl ring: 40 A – 170 A multiple processes 1
420323 Swirl ring: 60 A – 300 A multiple processes 2
420368 Water tube 2
420200 Shield retaining cap 2
420365 Nozzle retaining cap 2
104879 2.25 inch spanner wrench 1
104119 Consumable tool 1
027055 Silicone lubricant, 1/4 ounce 1
