Hypertherm XPR170 Replacement Part Procedures

Parts List
5
140 810410 Field Service Bulletin XPR170
Rear compartment of the plasma power supply
7 229679 Chopper assembly Chopper 1 1
229956 XPR170 wire harness – 1
223400
CAN cable 1 m (3.3 ft) (not shown)
Located between the control PCB and
Chopper 1.
–1
Part number Description Designator Quantity
1 229033
Terminal block 600 V, 200 A (200 V, 208 V,
220 V, 240 V)
TB1 1
2 209453
EMI filter with terminal block (400 V, 415 V
CE)
3 029316
Terminal block 600 V, 140 A (380 V, 440 V,
480 V, 600 V)
4
003276 Main contactor (200 V, 208 V, 220 V, 240 V)
M_CON 1
429060
Main contactor assembly (380 V, 400 V,
415 V, 440 V, 480 V, 600 V)
5 141511
VDC3 PCB (Optional, for use with RS-422
and discrete cutting systems)
– 1
Part number Description Designator Quantity
1
2
3
4
200 V, 208 V, 220 V, 240 V plasma
power supplies
400 V, 415 V (CE) plasma power
supplies
380 V, 440 V, 480 V, 600 V plasma
power supplies
5
5
5
4
4
