IBM DS5100 User Manual

Table 41. Cabling for five to eight EXP5060s, storage expansion enclosures 5 and 6 with drive-side trunking
Cable
Controller A Controller B Storage Expansion Enclosure 5
Ch1 Ch2 Ch3 Ch4 Ch5 Ch6 Ch7 Ch8 ESM A (Top) ESM B (Bottom)
87654321123456781A1B2A2B1A1B2A2B
1X X
2X X
Cable
Storage Expansion Enclosure 5 Storage Expansion Enclosure 6
ESM A (Top) ESM B (Bottom) ESM A (Top) ESM B (Bottom)
1A 1B 2A 2B 1A 1B 2A 2B 1A 1B 2A 2B 1A 1B 2A 2B
3X X
4X X
5XX
6XX
Cable
Controller A Controller B Storage Expansion Enclosure 6
Ch1 Ch2 Ch3 Ch4 Ch5 Ch6 Ch7 Ch8 ESM A (Top) ESM B (Bottom)
87654321123456781A1B2A2B1A1B2A2B
7XX
8XX
104 IBM System Storage DS5100 and DS5300 Storage Subsystem: Installation, User’s, and Maintenance Guide
