FRONT
Rack Mounting
Template
0 U
2 U
3 U
1 U
4 U
Rail assembly
(Front left)
Rail assembly
(Front right)
Rail assembly
(Front left)
Rail assembly
(Front right)
4 U
3 U
2 U
1 U
0 U
Front
Figure 13. DS5100 and DS5300 front rack mounting template
Chapter 2. Installing the storage subsystem 39
