REAR
Rack Mounting
Template
Rail assembly
(Rear left)
Rail assembly
(Rear right)
4 U
3 U
2 U
1 U
0 U
0 U
2 U
3 U
1 U
4 U
Printed in the U.S.A
Figure 129. DS5100 and DS5300 rear rack mounting template
Appendix C. Rack mounting templates 227
