Appendix C. Rack mounting templates
This appendix provides duplicate copies of the rack mounting templates. If you want
to tear out the templates from this document for easier use, use these copies rather
than those provided in “Installing the support rails” on page 38.
Use the following templates (Figure 128 on page 226 and Figure 129 on page 227)
to identify the proper locations for inserting M5 screws when mounting the support
rails and DS5100 and DS5300 in a rack cabinet. The locations for the M5 screws
are highlighted in the templates.
The DS5100 and DS5300 is 4 U high. Align the template with the rack at a U
boundary. U boundaries are shown as horizontal dashed lines in the rack mounting
templates.
Note: The mounting holes that are shown in the following templates are square.
The holes in your rack cabinet might be round or square.
© Copyright IBM Corp. 2009 225
