Table 6. RAID controller specifications (continued)
Category Criteria Specification
Storage expansion enclosure support Redundant drive channel pairs 4 per controller
Maximum number of drives per
redundant drive channel pair
112 drives per redundant drive
channel pair (Seven storage
expansion enclosures with 16 drives
each). See Table 3 on page 9.
Maximum number of drives supported
by one DS5100
224 drives standard. Supports up to
480 drives with purchase of the Attach
up to 448 drives feature pack and the
Attach up to eight EXP5060 feature
pack.
A premium feature is available to
provide support for up to 448 drives.
Maximum number of drives supported
by one DS5300
448 drives standard. Supports up to
480 drives with the purchase of the
Attached up to eight EXP5060 feature
pack.
Data transfer rates Fibre channel host Up to 8 Gb/sec maximum when 8
Gbps FC host interface cards are
used.
v Supports 1, 2, and 4 Gbps
auto-negotiated FC speeds when
using 4 Gbps host interface cards
v Supports 2, 4, and 8 Gbps
auto-negotiated FC speeds when
using 8 Gbps host interface cards
iSCSI host 1 Gb/sec maximum when 1 Gbps
iSCSI HICs are used.
Fibre channel drives 4 Gbps
SATA drives 3 Gbps
Ethernet 10BASE-T
100BASE-T
1000BASE-T
Power supply and fan units
The DS5100 and DS5300 have two power supply and fan units. Each power supply
and fan unit contains a power supply, a fan, and a battery charger. Each power
supply provides power to the controllers by converting incoming ac voltage to the
appropriate dc voltages. If one power supply and fan unit is turned off or
malfunctions, the remaining power supply and fan unit can maintain electrical power
and cooling to the storage subsystem.
Note: Contact IBM for information about possible future dc-to-dc power supply
support.
Install the power supply and fan units from the front of the storage subsystem.
Figure 7 on page 20 shows how a power supply and fan unit slides into the storage
subsystem. The levers that secure the left power supply and fan unit into the
Chapter 1. Introduction 19
