Table 2. Features at a glance
General
v Modular components:
– RAID controllers (2)
– Power supply-cooling fan units (2)
– Interconnect-battery unit (1)
v Technology:
– Support for RAID 0, 1, 3, 5 and 6
disk arrays
– Support of Full Disk Encryption (FDE)
disk drives. (Requires Premium
Feature Key)
– Storage capacity up to 480 TB
– DS5300 supports up to 480 physical
disk drives attached to storage
subsystem (requires the Attach up to
eight EXP5060 feature pack)
– DS5100 supports up to 480 physical
disk drives attached to storage
subsystem (requires the Attach up to
448 drives feature pack and the
Attach up to eight EXP5060 feature
pack)
– Controller cache size of 4 GB per
controller on the DS5100; 8 GB of
cache memory per controller on the
DS5300
– Cache memory upgradable to 32 GB
per controller for a total of 64 GB per
storage subsystem
– Support for clustering
– Fibre channel and iSCSI host
interface
– Support for FC or Serial Advanced
Technology Attachment (SATA) disks,
or a mix of both types of disks via
optional DS5100 and DS5300 Fibre
Channel/SATA Enclosure Intermix
feature
– Redundant controllers and power
supply/cooling system
– Hot-swap technology for controllers,
power supply and fan units, cache
battery, and interconnect-battery unit
v User interface:
– Built-in power, activity, and fault
(Needs Attention) light emitting
diodes (LEDs)
– Identification labeling on field
replaceable units (FRUs), rear LEDs,
switches, and connectors
– Easy-to-replace power supply and
fan units, RAID controllers, cache
battery, and interconnect-battery unit
RAID controllers
v Fibre channel interface. Each controller
has 16 small form-factor pluggable
(SFP) ports for incoming and outgoing
fibre-channel cables:
– 8 SFP ports per controller for storage
expansion enclosure connections
– Up to 8 SFP ports per controller for
host connections
v iSCSI interface. Each controller supports
up to four 1 Gbps iSCSI host ports.
v Host interface card. Each controller
supports up to two host interface cards.
Support for:
– 4 Gbps FC
– 8 Gbps FC
– 1 Gbps iSCSI
v Support for any combination of HICs, if
both controllers have the same type
HICs in identical slot positions.
Attached storage expansion enclosures
v Sixteen dual-ported drive channel
connections (8 per RAID controller)
enabled to support 4 Gbps fibre channel
connections
v Supports attachment of 4 Gbps
EXP5000 storage expansion enclosures
v Supports attachment of 4 Gbps
EXP5060 storage expansion enclosures
Options:
v FlashCopy
v VolumeCopy
v Enhanced Remote Mirroring
Clustering support
Clustering is a means of sharing array groups among controllers to provide
redundancy of controllers and servers. This redundancy is important if a hardware
component fails. If a hardware component failure occurs in a cluster, another server
takes ownership of the array group.
Clustering requires software specific to your operating system. For more information
about clustering, see www.ibm.com/servers/storage/disk/ds4000/interop-matrix.html.
Inventory checklist
After you unpack the DS5100 and DS5300, verify that you have the following items.
See “Storage subsystem components” on page 6 for the locations of hardware
components on the DS5100 and DS5300.
Chapter 1. Introduction 3
