Appendix B. Records
Whenever you add options to your DS5100 and DS5300, be sure to update the
information in this appendix. Accurate, up-to-date records make it easier to add
other options and provide needed data whenever you contact your IBM technical
support representative.
Identification numbers
Record and retain the following information. The machine type, model number, and
serial number are located on top of each RAID controller unit. The RAID controller
MAC addresses are located near the Ethernet ports on each RAID controller, the
iSCSI port MAC addresses are near the iSCSI ports, as shown in Figure 127 on
page 224.
Product name: IBM System Storage DS5100 and DS5300 Storage
Subsystem
Machine type: 1818
Model number:
Serial number:
RAID controller MAC addresses:
Controller firmware version:
Port name MAC address IP address Subnet mask
Controller A
management port 1
Controller A
management port 2
Controller B
management port 1
Controller B
management port 2
Controller A iSCSI
port 1
Controller A iSCSI
port 2
Controller A iSCSI
port 3
Controller A iSCSI
port 4
Controller B iSCSI
port 1
Controller B iSCSI
port 2
Controller B iSCSI
port 3
Controller B iSCSI
port 4
© Copyright IBM Corp. 2009 223
