General Checkout
Important
An external diskette drive must be attached to the
computer to run the diagnostics program from a
diskette. If an external diskette drive is not attached
to the computer, do the following.
1. Run the POST (Power-On Self Test).
2. If you receive an error, go to “Symptom-to-FRU
Index” on page 237.
3. If you suspect an undetermined problem, go to
“Undetermined Problems” on page 239.
1. Power-off the computer and all external devices.
2. Check all cables and power cords for correct
connection.
3. Insert the Advanced Diagnostics diskette into the
diskette drive.
4. Power-on all external devices.
5. Power-on the computer and check for one short beep
at the end of POST with a clear and readable
diagnostics menu displayed. If you did not get the
correct responses, go to “Symptom-to-FRU Index” on
page 237.
6. Run the advanced diagnostics tests. For information
on how to disable the password, see “Power-On
Password” on page 240.
7. Find your symptom below, then go to the appropriate
page. Otherwise, see “Symptom-to-FRU Index” on
page 237, then go to “Undetermined Problems” on
page 239.
Note
For information about how to run diagnostics, error
messages, passwords, and various other tests and
service checks, go to “Related Service Procedures” on
page 240.
Symptom Go to ...
Error Code or Message “Symptom-to-FRU Index” on
page 237
Configuration Problem “Checking the Installed
Devices List” on page 241
Power Problem “Power Systems Checkout”
on page 235
Memory Problem “Memory Checkout” on
page 233
TrackPoint II Problem “TrackPoint II Checkout” on
page 470
232 IBM Mobile Systems HMM - Volume 1
