Locations
System Board
.1/ External SCSI Connector
.2/ Serial Connector
.3/ Parallel Connector
.4/ Pointing Device Connector
.5/ Keyboard Connector
.6/ 120-Pin Connector
.7/ System Board-Sub Connector
.8/ Power Supply Connectors
.9/ Internal SCSI Cable Connector
.1ð/ System Board-Main Interface
.11/ Wire Assembly Connector
.12/ Backup Battery
.13/ 16-Bit Expansion Slots
336 IBM Mobile Systems HMM - Volume 1
