1110 Power Supply Unit
Bottom Cover (1010)
Main Board (1080)
Open the release/lock lever
Warning: When doing sequence .5/, remove the audio
card only enough to disconnect the power supply
connecters under the card. Do not pull the card out
because there are three more cables connected to the
card.
Step Color and type
(quantity)
Length
.1/ White screw (6) 5 mm (0.20 in.)
.2/ Black self tap screw (1) 8 mm (0.31 in.)
.4/ White screw (2) 5 mm (0.20 in.)
Note: Make sure you use the correct screw.
Dock I (3545) 377
