Related Service Procedures
This section provides information on the following:
“Status Indicators”
“PC Test Card LED”
“Power-On Password”
“Checking the Installed Devices List” on page 241
“Power-On Self Test (POST)” on page 241
“Advanced Diagnostics Diskette” on page 242
“Loading the Diagnostics Diskette” on page 242
“Formatting the Hard Disk Drive” on page 242
“Error Log” on page 243
“Setup Options” on page 244
“Starting Setup” on page 244
“Utilities” on page 245
Status Indicators
Light Status Indicated
Battery almost discharged
Battery is charging
(this indicator is on whenever the AC
adapter is connected to the computer)
Computer is powered-on
Computer is in suspend mode
Hard disk drive is active
Diskette drive is active
Keyboard is in Num Lock mode
Keyboard is in Caps Lock mode
Keyboard is in Scroll Lock mode
PC Test Card LED
The green LED on the PC test card lights when the
PCMCIA test is running. If the LED does not go on, check
that the card is installed correctly by reseating the card. If
it still does not light after reseating, try using another slot
for the test. If the LED still does not go on and the test
fails, replace the FRU shown in the diagnostic error code.
Power-On Password
240 IBM Mobile Systems HMM - Volume 1
