General Checkout
001
– Power-off the computer and all external devices.
– Remove the computer from the Dock I.
– Connect the external keyboard, mouse, parallel and
serial devices to the computer, if used. (Use the
keyboard/mouse connector for testing the external
keyboard and mouse.)
– Diagnose and resolve any computer problems first.
DID THE TEST COMPLETE WITHOUT ANY ERRORS?
Yes No
002
Diagnose and resolve any computer problems first.
003
– Install the computer on the Dock I. Make sure that the
computer is firmly connected.
– Check all cables and power cords.
– Check the fan in the power supply in the Dock I and
make sure it is working correctly.
Notes:
1. The mouse or other pointing devices do not work if
they are connected to the keyboard/numeric
keypad connector.
2. The mouse or other pointing devices do not work if
they are connected to the mouse connector on the
numeric keypad that is connected to the Dock I.
3. The computer keyboard does not work when an
external keyboard is connected to the Dock I.
– Reinstall all external devices.
– Power-on all external devices.
– Press and hold F1, then power-on the computer. (Hold
F1 until the Easy-Setup screen or an error message
appears.)
Note: If the warning beep sounds for the correct
operation, go to “Symptom-to-FRU Index” on
page 351.
– Write down all post error codes that are displayed.
(Press the Pause key when an error code appears to
keep the screen from scrolling. Press F1 to continue.)
If the POST stops and you cannot continue, go to
“Symptom-to-FRU Index” on page 351.
(Step 003 continues)
Dock I (3545)
341
To Next Page
