Replacement
Note
The intersecting end of the SCSI cable should be
inserted into the connector on the riser card. See .1/.
Step Color and type (quantity) Length
.2/ Pan head screw (1)
Diameter: 3 mm (0.12 in.)
8 mm
(0.31 in.)
Flat head screw (1)
Diameter: 3 mm (0.12 in.)
6 mm
(0.24 in.)
.4/ Pan head screw (6)
Diameter: 3 mm (0.12 in.)
6 mm
(0.24 in.)
.5/ Pan head screw (2)
Diameter: 3 mm (0.12 in.)
4 mm
(0.16 in.)
.7/ Binding head tapping screw
(2)
Diameter: 3 mm (0.12 in.)
6 mm
(0.24 in.)
.8/ Black binding head machine
screw (4)
Diameter: 3 mm (0.12 in.)
6 mm
(0.24 in.)
.9/ Pan head screw (2)
Diameter: 3 mm (0.12 in.)
6 mm
(0.24 in.)
Dock II (3546) 435
