Weight of expansion enclosure SAS drives
The SAS drives are shipped in a separate package from the 2076-92F expansion
enclosure. The enclosure can support up to 92 SAS drives; however, the quantity
varies depending on the number of drives ordered.
Table 10 summarizes the weights of the SAS drives that are supported in the
2076-92F expansion enclosure. Storwize V7000 Gen2 and Storwize V7000 Gen2+
systems that are running software level 7.8 can support the 2076-92F expansion
enclosure.
Table 10. Weight of expansion enclosure drives
FRU description FRU part number Feature code
Approximate weight per unit
kg lb
600 GB 15 K 2.5-inch
hard disk drive
01LJ061 AH70 0.304 0.670
1.2 TB 10 K 2.5-inch
hard disk drive
01LJ062 AH73 0.304 0.670
1.8 TB 10 K 2.5-inch
hard disk drive
01LJ063 AH74 0.304 0.670
6 TB 7.2 K 3.5-inch
Near-Line SAS hard
disk drive
01LJ064 AH77 0.876 1.931
8 TB 7.2 K 3.5-inch
Near-Line SAS hard
disk drive
01LJ065 AH78 0.876 1.931
10 TB 7.2 K 3.5-inch
Near-Line SAS hard
disk drive
01LJ066 AH79 0.876 1.931
1.6 TB 2.5-inch tier 0
flash drive
01LJ067 AH7D 0.224 0.494
3.2 TB 2.5-inch tier 0
flash drive
01LJ068 AH7E 0.224 0.494
1.92 TB 2.5-inch tier 1
flash drive
01LJ069 AH7J 0.224 0.494
3.84 TB 2.5-inch tier 1
flash drive
01LJ070 AH7K 0.224 0.494
7.6 8 TB 2.5-inch tier
1 flash drive
01LJ071 AH7L 0.224 0.494
15.36 TB 2.5-inch tier
1 flash drive
01LJ072 AH7M 0.224 0.494
Weight increases as FRUs are installed
The 2076-92F expansion enclosure supports up to 92 SAS drives. As Table 11 on
page 36 shows, substantial weight is added to the enclosure when all drives are
installed.
Chapter 2. Installing the Storwize V7000 Gen2 and Storwize V7000 Gen2+ hardware 35
