v Ensure that a suitably rated mechanical lift is available to support the weight of
the expansion enclosure as it inserted into the rack for installation.
About this task
The 2076-92F expansion enclosure and most parts are shipped together in one large
box. A tray on top of the enclosure contains the front fascia (1U and 4U pieces), the
cable management arm (CMA), and the slide rail kit; you must install these parts.
Figure 29 shows how the enclosure is packaged for shipment.
▌1▐ Slide rail kit
▌2▐ Cable management arm
▌3▐ Fascia
Other parts, such as the cover, secondary expander modules, and fans, are installed
in the enclosure. However, due to weight considerations, you must remove some
parts and then reinstall them as part of the initial installation process.
Note: Drives are not included in installation package for the enclosure; they are
provided in a separate package.
Procedure
1. Remove the cardboard tray that contains the slide rails, cable management
arm, and fascia from cardboard box in which the expansion enclosure was
shipped.
2. Remove the foam end pieces from the top of the 2076-92F expansion
enclosure.
3. Cut the corners of the shipping box and fold them down to uncover the sides
and faces of the expansion enclosure, as shown in Figure 30 on page 43.
Figure 29. Tray containing expansion enclosure parts
42 Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
