Table 6. IMM2 error messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v If an action step is preceded by “(Trained technician only),” that step must be performed only by a trained
technician.
806f0a13-0301xxxx A Fatal Bus Error has
occurred on system
CPU 1 PECI.
Error A bus fatal error
has been detected.
1. Reseat the microprocessor, and
then restart the server.
2. Replace microprocessor n.
(n = microprocessor number)
806f0125-1001xxxx
806f0125-1002xxxx
The entity of PCI
riser has been
detected absent for
PCI n.
(n = PCI slot number)
Info The entity of PCI
riser n has been
detected absent.
(n = PCI slot
number)
No action; information only.
80010701-1001xxxx
80010701-1002xxxx
Sensor PCI riser n
Temp going high
(upper non-critical)
has asserted.
(n = PCI slot number)
Warning An upper
non-critical sensor
going high has
asserted.
1. Reduce the ambient temperature.
2. Check the server airflow. Make sure
that nothing is blocking the air from
coming into or preventing the air
from exiting the server.
80010901-1001xxxx
80010901-1002xxxx
Sensor PCI riser n
Temp going high
(upper critical) has
asserted.
(n = PCI slot number)
Error An upper critical
sensor going high
has asserted.
1. Reduce the ambient temperature.
2. Check the server airflow. Make sure
that nothing is blocking the air from
coming into or preventing the air
from exiting the server.
80010b01-1001xxxx
80010b01-1002xxxx
Sensor PCI riser n
Temp going high
(upper
non-recoverable) has
asserted.
(n = PCI slot number)
Error An upper
non-recoverable
sensor going high
has asserted.
Check the server airflow. Make sure
that nothing is blocking the air from
coming into or preventing the air from
exiting the server.
806f0125-2c01xxxx The entity of Mezz
Card has been
detected absent.
Info The entity of
dual-port network
adapter has been
detected absent.
1. Reseat the dual-port network
adapter (see “Removing the
optional dual-port network adapter”
on page 224 and “Installing the
optional dual-port network adapter”
on page 225).
2. Replace the dual-port network
adapter.
Chapter 3. Diagnostics 85

IBM System x3650 M4 Type 7915 Specifications

General

Form Factor	2U Rack
Chipset	Intel C600 series chipset
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Up to two Intel Xeon E5-2600 series processors
Memory	Up to 768GB DDR3 (24 DIMM slots)
Storage	Up to 16 x 2.5" or 6 x 3.5" SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 10
Network	Four integrated Gigabit Ethernet ports
Power Supply	Up to two redundant hot-swap 550 W, 750 W, or 900 W power supplies
Expansion Slots	Up to 7 PCIe 3.0 slots
Storage Controller	ServeRAID M5110e
Management	Integrated Management Module (IMM) v2
