IBM System x3650 M4 Type 7915 Problem Determination And Service Guide

Table 6. IMM2 error messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v If an action step is preceded by “(Trained technician only),” that step must be performed only by a trained
technician.
806f0021-3001xxxx Mezz Card Error has
been detected.
Error A dual-port network
adapter fault has
been detected.
1. Check the optional network adapter
error LED.
2. Reseat the dual-port network
adapter (see “Removing the
optional dual-port network adapter”
on page 224 and “Installing the
optional dual-port network adapter”
on page 225).
3. Update the firmware (UEFI and
IMM) (see “Updating the firmware”
on page 297) and dual-port network
adapter driver to the latest level.
4. Replace the dual-port network
adapter.
5. (Trained technicians only) Replace
the system board (see “Removing
the system board” on page 290 and
“Installing the system board” on
page 292).
80070221-d001xxxx Sensor PCIe
configuration has
transitioned to critical
from a less severe
state.
A sensor has
changed to critical
state from a less
severe state.
130W or 135W microprocessors
system configuration only.
86 IBM System x3650 M4 Type 7915: Problem Determination and Service Guide

IBM System x3650 M4 Type 7915 Specifications

General

Form Factor	2U Rack
Chipset	Intel C600 series chipset
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Up to two Intel Xeon E5-2600 series processors
Memory	Up to 768GB DDR3 (24 DIMM slots)
Storage	Up to 16 x 2.5" or 6 x 3.5" SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 10
Network	Four integrated Gigabit Ethernet ports
Power Supply	Up to two redundant hot-swap 550 W, 750 W, or 900 W power supplies
Expansion Slots	Up to 7 PCIe 3.0 slots
Storage Controller	ServeRAID M5110e
Management	Integrated Management Module (IMM) v2
