IBM System x3650 M4 Type 7915 Problem Determination And Service Guide

Table 7. Light path diagnostics panel LEDs (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v If an action step is preceded by "(Trained technician only)," that step must be performed only by a trained
technician.
LED Description Action
BOARD An error has occurred on the
system board or the system
battery.
1. Check the LEDs on the system board to identify the
component that caused the error. The BOARD LED can
be lit due to any of the following reasons:
v Battery
v (Trained technician only) System board
2. Check the system-error log for information about the error.
3. Replace the failing component:
v Battery (see “Removing the battery” on page 273 and
“Installing the battery” on page 275).
v (Trained service technician only) System board (see
“Removing the system board” on page 290 and
“Installing the system board” on page 292).
HDD A hard disk drive has failed or is
missing.
1. If the CONFIG LED is not lit, complete the following steps
to correct the problem:
a. Check the LEDs on the hard disk drives for the drive
with a lit status LED and reseat the hard disk drive.
b. Reseat the hard disk drive backplane.
c. For more information, see “Hard disk drive problems”
on page 104.
d. If the error remains, replace the following components
one at a time, in the order listed, restarting the server
after each:
1) Replace the hard disk drive.
2) Replace the hard disk drive backplane.
e. If the problem remains, go to http://www.ibm.com/
systems/support/supportsite.wss/
docdisplay?brandind=5000008&lndocid=SERV-CALL.
2. If the HDD LED and the CONFIG LED are lit, complete
the following steps to correct the problem:
a. Check the microprocessor installed is Intel E5-2690. If
it is, check the 2.5-inch hard disk drives installed is
lesser than eight.
b. Check the system-error logs for information about the
error. Replace any component that is identified in the
error log.
134 IBM System x3650 M4 Type 7915: Problem Determination and Service Guide

IBM System x3650 M4 Type 7915 Specifications

General

Form Factor	2U Rack
Chipset	Intel C600 series chipset
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Up to two Intel Xeon E5-2600 series processors
Memory	Up to 768GB DDR3 (24 DIMM slots)
Storage	Up to 16 x 2.5" or 6 x 3.5" SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 10
Network	Four integrated Gigabit Ethernet ports
Power Supply	Up to two redundant hot-swap 550 W, 750 W, or 900 W power supplies
Expansion Slots	Up to 7 PCIe 3.0 slots
Storage Controller	ServeRAID M5110e
Management	Integrated Management Module (IMM) v2
