IBM System x3650 M4 Type 7915 Problem Determination And Service Guide

Table 11. Parts listing, Type 7915 (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
5 Heat sink retention module 94Y7739
6 Memory, 8 GB dual-rank 1.35V, DDR3, 1333MHz, RDIMM 49Y1415
6 Memory, 8 GB quad-rank 49Y1417
6 Memory, 4 GB dual-rank 1.35V, DDR3, 1333MHz, UDIMM 49Y1422
6 Memory, 2 GB single-rank 1.35V, DDR3, 1333MHz, RDIMM 49Y1423
6 Memory, 4 GB single-rank 1.35V, DDR3, 1333MHz, RDIMM 49Y1424
6 Memory, 4 GB dual-rank 1.35V, DDR3, 1333MHz, RDIMM 49Y1425
6 Memory, 4 GB single-rank 1.5 V, DDR3, 1600MHz, RDIMM 49Y1561
6 Memory, 16 GB dual-rank 1.35V, DDR3, 1333MHz, RDIMM 49Y1565
6 Memory, 8 GB dual-rank 1.5 V, DDR3, 1600MHz, RDIMM 90Y3111
6 Memory, 4 GB dual-rank 1.5 V, DDR3, 1600MHz, RDIMM 90Y3180
6 Memory, 16 GB quad-rank 1.5V DDR3, 1333MHz LP Hyper Cloud
DIMM
00D4966
6 Memory, 16 GB dual-rank 1.5 V, DDR3, 1600MHz, RDIMM 00D4970
6 Memory, 32 GB dual-rank 1.35 V, DDR3, 1333MHz, LRDIMM 90Y3107
6 Memory, 32 GB single-rank 1.5V DDR3, 1066MHz LP Hyper Cloud
DIMM
00D5006
7 System board 00D2888
9 Power supply, 550 Watt, high efficiency, ac 43X3312
9 Power supply, 550 Watt, ac 94Y8075
9 Power supply, 750 Watt, high efficiency, ac 69Y5747
9 Power supply, 750 W, ac 94Y8071
9 Power supply, 750 W, ac 94Y8086
9 Power supply, 900 Watt, ac 94Y8067
9 Power supply, 900 Watt, ac 94Y8073
9 Power supply, 900 Watt, ac 94Y8087
9 Power supply, 750 W, high efficiency, -48 V, dc 69Y5742
10 DVD drive, SATA 44W3254
10 DVD drive, SATA 44W3256
11 Operator information panel assembly 90Y5821
Filler, 3.5-inch hard disk drive bay for hot-swap 69Y5364
Filler, 3.5-inch hard disk drive bay for simple-swap 69Y5368
14 Filler, hard disk drive bay for simple-swap 49Y5360
15 Tape kit (optional) contains:
v Assembly, mechanical (1)
v Clamp, round cable (1)
v Filler, tape kit 3.5 inch (1)
v Screws, M3x6 MPC (4)
40K6449
Plus 8 pac 2.5-inch hard disk drive backplane assembly 90Y5875
182 IBM System x3650 M4 Type 7915: Problem Determination and Service Guide

IBM System x3650 M4 Type 7915 Specifications

General

Form Factor	2U Rack
Chipset	Intel C600 series chipset
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Up to two Intel Xeon E5-2600 series processors
Memory	Up to 768GB DDR3 (24 DIMM slots)
Storage	Up to 16 x 2.5" or 6 x 3.5" SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 10
Network	Four integrated Gigabit Ethernet ports
Power Supply	Up to two redundant hot-swap 550 W, 750 W, or 900 W power supplies
Expansion Slots	Up to 7 PCIe 3.0 slots
Storage Controller	ServeRAID M5110e
Management	Integrated Management Module (IMM) v2
