IBM System x3650 M4 Type 7915 Problem Determination And Service Guide

Table 11. Parts listing, Type 7915 (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
16 8 pac 2.5-inch hard disk drive backplane assembly 94Y7751
18 Fan cage 94Y6621
19 Fan 94Y6620
Battery, ServeRAID-M5100 Series 81Y4491
Hard disk drive, 200 GB SATA 43W7721
Hard disk drive, 200 GB SSD 43W7745
Hard disk drive, 2.5-inch hot-swap, 900 GB, 10 K 81Y9651
Hard disk drive, 300 GB SAS 81Y9671
Hard disk drive, 2.5-inch hot-swap, 1 TB, 7.2 K 81Y9691
Hard disk drive, 2.5-inch hot-swap, 250 GB, 7.2 K 81Y9723
Hard disk drive, 2.5-inch hot-swap, 500 GB, 7.2 K 81Y9727
Hard disk drive, 2.5-inch hot-swap, 1 TB, 7.2 K 81Y9731
Hard disk drive, 3.5-inch hot-swap, 500 GB, 7.2 K, NL SATA 81Y9787
Hard disk drive, 3.5-inch hot-swap, 1 TB, 7.2 K 81Y9791
Hard disk drive, 3.5-inch hot-swap, 2 TB, 7.2 K, NL SATA 81Y9795
Hard disk drive, 3.5-inch hot-swap, 3 TB, 7.2 K 81Y9799
Hard disk drive, 3.5-inch simple-swap, 500 GB, 7.2 K 81Y9803
Hard disk drive, 3.5-inch simple-swap, 1 TB, 7.2 K 81Y9807
Hard disk drive, 3.5-inch simple-swap, 2 TB, 7.2 K 81Y9811
Hard disk drive, 3.5-inch simple-swap, 3 TB, 7.2 K 81Y9815
Hard disk drive, 3.5-inch hot-swap, 1 TB, 7.2 K, NL SAS 90Y8568
Hard disk drive, 3.5-inch hot-swap, 2 TB, 7.2 K, NL SAS 90Y8573
Hard disk drive, 3.5-inch hot-swap, 3 TB, 7.2 K, NL SAS 90Y8578
Hard disk drive, 2.5-inch hot-swap, 600 GB, 10 K 90Y8873
Hard disk drive, 300 GB 10 K SAS (Gen2) 90Y8878
Hard disk drive, 2.5-inch hot-swap, 300 GB, 10 K, SAS SED 90Y8914
Hard disk drive, 146 GB 15 K SAS (Gen2) 90Y8927
Hard disk drive, 146 GB 15 K 6 Gbps SAS 2.5-inch SFF (Gen 2)
hot-swap SED
90Y8945
Hard disk drive, 500 GB 7.2K SAS (Gen2) 90Y8954
Hard disk drive, 2.5-inch, 1 TB 7.2K hot-swap SAS SAP 90Y8866
Solid state drive, 200 GB 40K6897
Solid state drive, 50 GB 43W7729
Solid state drive, 2.5-inch hot-swap, SATA, 256 GB 90Y8644
Solid state drive, 2.5-inch hot-swap, SATA, 128 GB 90Y8649
Solid state drive, 2.5-inch simple-swap, SATA, 256 GB 90Y8664
Solid state drive, 2.5-inch simple-swap, SATA, 128 GB 90Y8669
Solid state drive file, 1.8-inch 49Y4936
Solid state drive backp cage, 1.8-inch 59Y6222
Chapter 4. Parts listing, Type 7915 server 183

IBM System x3650 M4 Type 7915 Specifications

General

Form Factor	2U Rack
Chipset	Intel C600 series chipset
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Up to two Intel Xeon E5-2600 series processors
Memory	Up to 768GB DDR3 (24 DIMM slots)
Storage	Up to 16 x 2.5" or 6 x 3.5" SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 10
Network	Four integrated Gigabit Ethernet ports
Power Supply	Up to two redundant hot-swap 550 W, 750 W, or 900 W power supplies
Expansion Slots	Up to 7 PCIe 3.0 slots
Storage Controller	ServeRAID M5110e
Management	Integrated Management Module (IMM) v2
