IBM System x3650 M4 Type 7915 Problem Determination And Service Guide

Table 11. Parts listing, Type 7915 (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
HBA 4 GB FC PCI-e single port adapter 39R6526
HBA 4 GB FC PCI-e dual port adapter 39R6528
NetXtreme II 1000 Express Ethernet adapter 39Y6070
PRO 1000 PF server adapter 42C1752
QLogic 10 GB dual port CNA 42C1802
Qlogic 10 GB SFP+ SR optical transceiver 42C1816
Qlogic dual-port 10GbE SFP+ Embedded VFA 90Y5099
Brocade 10GB SFP+ SR optical transceiver 42C1819
HBA 10 GB adapter 42C1822
Emulex 8 GB PCIe single port adapter 42D0491
Emulex 8 GB PCIe dual port adapter 42D0500
Qlogic 8 GB single port adapter 42D0507
HBA 8 GB adapter 42D0516
Video adapter, NVIDIA Quadro 600 43V5931
Video adapter, NVIDIA Quadro 2000 43V5939
Video adapter, NVIDIA Quadro FX4000 PCI Express x 16 90Y2330
Video adapter, NVIDIA Quadro 6000 with passive heatsink PCI
Express x 16
90Y2332
FC 4 GB PCIe single port adapter 43W7510
FC 4 GB PCIe dual port adapter 43W7512
IBM 6 Gb Performance Optimized HBA 46C8937
6 Gb SSD HBA 46M0913
Brocade 8 GB single port adapter 46M6061
Brocade 9 GB dual port adapter 46M6062
Dual port adapter 49Y4232
Quad port adapter 49Y4242
Broadcom NetXtreme II 10 GB dual port BaseT adapter 49Y7912
NetXtreme II 1000 Express dual port Ethernet adapter 49Y7947
NetXtreme II 1000 Express quad port Ethernet adapter 49Y7949
X520-DA2 10 GB Express dual port SFP+ adapter 49Y7962
Brocade HBA 4 GB FC single port 59Y1992
Brocade HBA 4 GB FC dual port 59Y1998
HBA 6 GB adapter SAS 68Y7354
IBM LLM-SM Dual Port 10Gbe SFP+ Adaptor 00D9502
Emulex 16Gb FC Single-port HBA 81Y1658
Emulex 16Gb FC Dual-port HBA 81Y1665
Brocade 16Gb FC Single-port HBA 81Y1671
Brocade 16Gb FC Dual-port HBA 81Y1678
6 GB performance optimized HBA 90Y4356
184 IBM System x3650 M4 Type 7915: Problem Determination and Service Guide

IBM System x3650 M4 Type 7915 Specifications

General

Form Factor	2U Rack
Chipset	Intel C600 series chipset
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Up to two Intel Xeon E5-2600 series processors
Memory	Up to 768GB DDR3 (24 DIMM slots)
Storage	Up to 16 x 2.5" or 6 x 3.5" SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 10
Network	Four integrated Gigabit Ethernet ports
Power Supply	Up to two redundant hot-swap 550 W, 750 W, or 900 W power supplies
Expansion Slots	Up to 7 PCIe 3.0 slots
Storage Controller	ServeRAID M5110e
Management	Integrated Management Module (IMM) v2
