MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Continued ( Sentence formatter setting)
• RMC : (Default OFF)
Set RMC sentence ON or OFF.
• GGA : (Default ON)
Set GGS sentence ON or OFF.
• GLL : (Default OFF)
Set GLL sentence ON or OFF.
• GSA : (Default OFF)
Set GSA sentence ON or OFF.
• VTG : (Default OFF)
Set VTG sentence ON or OFF.
• GSV : (Default OFF)
Set GSV sentence ON or OFF.
GPS-A set mode
Enter GPS-A set mode by selecting "DVA" in GPS-TX mode,
then push [
](5). This set mode is available to set unproto
address, data extension, time stamp, GPS-A symbol and
comment.
Unproto Address (UNPROT)
56 characters address can be entered for unproto address.
q Push [
](5) to enter the unproto address edit mode.
w Push [](2) or [](8) to select the desired character.
• The selected character blinks.
• Push [](6) to move the cursor right; push [](4) to move the
cursor left.
• Push [CLR](1) to erase the selected character, or push and hold
[CLR](1) for 1 sec. to erase all characters following the cursor.
e Repeat step w until the desired unproto address is pro-
grammed.
r Push [
](5) to program the unproto address and exit the
unproto address edit mode.
t Push [
](4) to return to GPS-A set mode screen.
To Next Page
