Section 9 - Fault Finding
110 Installation and Maintenance
FAULT FINDING
Is the wiring assembly from the Compressor connected
correctly to the Compressor and the Inverter?
Disconnect compressor. Are compressor
terminal resistances U to V, U to W and V to W
Disconnect the wiring assembly. Connect the assembly
to the Inverter Tester. Is the Inverter defective?
Replace the Compressor.
Make sure that the wiring assembly from
the Compressor is correctly attached to
the Compressor and the Inverter.
Replace the Compressor.
Replace the Inverter.
NO
NO
YES
YES
YES
YES
9.1.34 Compressor Stall Error and Compressor Start Error and Compressor Terminals Short Circuit
(L61) and Compressor Error
ᘐ WARNING: Set the power supply to OFF. Wait for a minimum of 10 minutes before you work on the appliance.
This is to let harmful electrical charges decrease to below a safe limit.
To Next Page
