Programming IDEC SmartRelay
105
IDEC SmartRelay Manual
Utilization of memory areas
The system indicates that there is insufficient memory space
by not allowing you to add a further block to your circuit pro
-
gram. IDEC SmartRelay offers you only the blocks for which
it can provide sufficient memory space. If IDEC SmartRelay
memory space is insufficient to hold any further blocks you
select from a block list, the system will deny access to this
list.
If memory space is fully occupied, optimize your circuit pro-
gram, or install a second IDEC SmartRelay.
Counter
Up/down counter 24 5
Operating hours counter 24 9
Frequency trigger 16 -
Analog
Analog trigger 16 -
Analog differential trigger 16 -
Analog comparator 24 -
Analog value monitoring 20 -
Analog amplifier 12 -
Analog multiplexer 20 -
Analog Ramp Control 36 -
PI controller 40 2
Others
Latching relay 8 1
Current impulse relay 12 1
Message texts 8 -
Softkey 8 2
Shift register 12 1
(1): Bytes in the Rem memory area, if retentivity is enabled.
Function Program
memory
Rem
memory
(1)
