IDEC SmartRelay FL1D Series User Manual

293 IDEC SmartRelay Manual
A Technical data
A.1 General technical data
Criterion Tested in
accordance with
Values
IDEC SmartRelay
Base:
Dimensions (WxHxD)
Weight
Installation
72 x 90 x 55 mm
Approx. 190 g
on a 35 mm profile rail
4 module widths
or wall mounting
IDEC SmartRelay
expansion module:
Dimensions (WxHxD)
Weight
Installation
36 x 90 x 53 mm
Approx. 90 g
on a 35 mm profile rail
2 module widths
or wall mounting
Climatic conditions
Ambient temperature
Horizontal installation
Vertical installation
Low temperature to
IEC 60068-2-1
High temperature to
IEC 60068-2-2
0 ... 55 °C
0 ... 55 °C
Storage/shipping -40 °C... +70 °C
Relative humidity IEC 60068-2-30 From 10 to 95 %
no condensation
Air pressure 795 ... 1080 hPa
Pollutants IEC 60068-2-42
IEC 60068-2-43
SO
2
10 cm
3
/m
3
,
4 days
H
2
S 1 cm
3
/m
3
,
4 days
Ambient mechanical conditions
Protection mode IP20
Vibrations: IEC 60068-2-6 5 ... 9 Hz (constant
amplitude 3.5 mm)
9 ... 150 Hz (constant
acceleration 9.8m/s
2
)
Shock IEC 60068-2-27 18 shocks
(half-sine wave 147m/
s
2
/11 ms)
Drop IEC 60068-2-31 Drop height 50 mm
