IDEC SmartRelay Manual 248
6.3 Copying data from the IDEC SmartRelay
to the memory cartridge (card)
To copy the circuit program to the memory cartridge (card):
1. Insert the memory cartridge (card) into the slot.
2. Switch the IDEC SmartRelay to programming mode
(ESC / >Stop).
3. The main menu opens. To select the ‘Card’ command:
Press ▲ or ▼
4. Press OK. The transfer menu opens.
5. Move the ‘>’ cursor to ‘IDEC SmartRelay → Card’ (if re-
quired)
Press ▲ or ▼
6. Press OK.
IDEC SmartRelay now copies the circuit program to the
memory cartridge (card).
When IDEC SmartRelay has finished copying, it automati-
cally returns you to the main menu:
>Program..
Card..
Setup..
Start
>Program..
Card..
Setup..
Start
IDEC SmartRelay main menu
> Card
Card
CopyProtect
= IDEC
SmartRelay
