IDEC SmartRelay installation and wiring
27
IDEC SmartRelay Manual
2.3.1 Connecting the power supply
IDEC SmartRelays (FL1D-*12RCC, FL1B-M08C2R2) are
suitable for nominal line voltages of 100 V AC/DC and 240 V
AC/DC. IDEC SmartRelays (FL1D-*12RCA, FL1B-
M08D2R2) are suitable for a supply voltage of 24 V AC/DC.
IDEC SmartRelays (FL1D-H12SND, FL1B-M08B1S2) are
suitable for a supply voltage of 24 V DC. IDEC SmartRelays
(FL1D-*12RCE, FL1B-M08B2R2) are suitable for a supply
voltage of 12 V AC/DC or 24 V AC/DC.
Note the information on connection in the product informa-
tion document shipped with your device and the technical
specifications in Appendix A relating to permissible voltage
tolerances, line frequency and current consumption.
Note
A power failure may cause an additional edge triggering signal at
the special functions, for example.
Data of the last uninterrupted
cycle are stored in IDEC SmartRelay.
