IDEC SmartRelay FL1D Series User Manual

Technical data
IDEC SmartRelay Manual 310
A.8 Technical data: FL1D-K2B2
FL1D-K2B2
Power supply
Input voltage 24 V DC
Permissible range 20.4 ... 28.8 V DC
Power consumption 25 ... 50 mA
Voltage failure buffering typ. 5 ms
Power loss at 24 V 0.6 ... 1.2 W
Electrical isolation No
Reverse polarity protection Yes
Ground terminal for connecting ground and shielding of
the analog measuring line.
Analog outputs
Number 2
Input range 0 ... 10 V DC
Load resistor 5 k
Ω
Resolution 10 bit, normalized to 0 ... 1000
Cycle time for analog value output depending on installation (typ. 50 ms)
Electrical isolation No
Line length
(shielded and twisted)
10 m
Error limit ±2.5 % of full scale
Short circuit protection Yes
Response at short-circuit affected output = 0 V
neighboring output reverts
Overload protection Yes
Response at overload affected output = 0 V
neighboring output reverts
