IDEC SmartRelay installation and wiring
19
IDEC SmartRelay Manual
2.2 Installing/removing IDEC SmartRelay
Dimensions
The IDEC SmartRelay installation dimensions are compliant
with DIN
43880.
IDEC SmartRelay can be snap-mounted to 35 mm DIN rails
to EN
50022 or on the wall.
IDEC SmartRelay width:
IDEC SmartRelay Base has a width of 72 mm, which cor-
responds with 4 subunits.
IDEC SmartRelay expansion modules have a width of
36 mm, which corresponds with 2 subunits.
Note
The figure below shows you an example of the installation
and removal of a FL1D-H12RCC and a digital module. The
measures shown apply to all other IDEC SmartRelay Base
versions and expansion modules.
!
Warning
Always switch off power before you “remove” and “insert” a module
(base module, expansion module, communication module).
