IDEC SmartRelay FL1D Series User Manual

Technical data
IDEC SmartRelay Manual 298
A.3 Technical data: FL1D-H12SND and FL1B-
M08B1S2
FL1D-H12SND FL1B-M08B1S2
Power supply
Input voltage 24 V DC 24 V DC
Permissible range 20.4 ... 28.8 V DC 20.4 ... 28.8 V DC
Reverse polarity protection Yes Yes
Permissible mains frequency
Power consumption from 24 V
DC
30 ... 55 mA
0.3 A per output
30 ... 45 mA
0.3 A per output
Voltage failure buffering
Power loss at 24 V 0.7 ... 1.3 W 0.8 ... 1.1 W
Backup of the real-time clock
at 25°C
Accuracy of the real-time
clock
Digital inputs
Number 8 4
Electrical isolation No No
Input voltage
• Signal 0
• Signal 1
L+
< 5 V DC
> 12 V DC
L+
< 5 V DC
> 12 V DC
(1)
Input current at
• Signal 0
• Signal 1
< 0.85mA (I1...I6)
< 0.05 mA (I7, I8)
> 2 mA (I1...I6)
> 0.15 mA (I7, I8)
< 0.85mA
(2)
> 2 mA
(3)
Delay time at
• 0 to 1
• 1 to 0
typ. 1.5 ms (I1...I4)
<1.0 ms (I5, I6)
typ. 1.5 ms (I1...I4)
<1.0 ms (I5, I6)
typ. 1.5 ms
typ. 1.5 ms
Line length (unshielded) 100 m 100 m
